Q5 Laser Scanner for 2D and 3D Measurements
The QuellTech Q5 laser scanner series offers an advantageous combination of compact design, high resolution, and fast scan rates. The Q5 laser scanners are highly versatile and can be used in a wide range of measurement applications. They are particularly well-suited for inline dimension inspections in confined spaces and are ideal for demanding environments affected by heat, ambient light, or dust.
Advantages of Q5 Laser Scanners
The Q5 laser scanners provide high scan rates in a compact design, offering calibrated measurement data in millimetres for the X and Z axes via Ethernet. Key features include high resolution, a profile speed of 14,000 profiles per second, and up to 28 million points per second. Available laser wavelengths are 405/450 nm (blue) and 650 nm (red), with optical power levels from 1 mW to 500 mW, allowing flexibility for light-absorbing surfaces.
