Automotive Measuring Systems

Tie-rod Loadcell TCLT-NA

The TCLT-NA is a load cell designed to measure the tensile and compressive force applied to the tie-rod of a car.

Features

  • Easy installation using the connection thread between the tie-rod and the tie-rod end
  • 3 kinds of threads prepared for installation on various tie-rods
  • 6 types are available depending on the combination of thread and capacity

Steering Torque and Angle Transducer HLA-50B

This is a steering torque and angle transducer for evaluation test of traveling performance of a car. It can be easily mounted on the existing steering wheel. It features high accuracy and excellent operability.

Features

  • Installation is possible on cars of various types (applicable to steering outer-diameter of 240-400mm)
  • Easily attached and detached
  • Excellent operability
  • Steering torque is detected by strain gauges, and torque output by telemetry

Braking Pedal Force Transducer MLA-NA

This is a load cell to measure the brake pedal force. It can easily be attached without modifying the pedal.

Features

  • Easy installation
  • Constructed thin and light
  • A little measurement error caused by the position to step on the pedal
  • Comes with a hook for displacement transducer wire
